HI-CAP TR 080702 P-2 Inch Tapered Roller Bearing For Industrial 38.55X72X15.8/15

Brand Name : QRL

Model Number : TR 080702 P-2

Certification : ISO9001/2000

Place of Origin : CHINA

MOQ : 10

Price : Negotiable

Payment Terms : L/C, D/A, T/T, M/T, D/D, CASH, D/P

Supply Ability : 10000

Delivery Time : 1-16 Working

Packaging Details : Carton/woven bag

Type : Taper Roller Bearing

Number of row : TR 080702 P-2

Inch : 38.55X72X15.8/15

Cage Material : ISO9001:2008 Standard

Weight : 0.285 kg/pcs

OEM : TR080702/1D 90368-38010

Contact Now

Designation: HI-CAP TR 080702 P-2 Inch Tapered Roller Bearing 38.55X72X15.8/15

Tapered Roller Bearing Specification

Main dimensions:

d mm⁄inch	D mm⁄inch	T mm⁄inch	B mm⁄inch	Mass kg⁄lb ➁
38.200	68.100	18.650	18.650	0.285
1.5039	2.6811	47⁄64	47⁄64	0.628

Taper Roller Bearing Description

Tapered roller bearings are used in a variety of industrial applications. The tapered rollers allow the bearings to accommodate heavy radial, axial and combination loads. This loading flexibility combined with a variety of configurations can be designed from single cups, double cups, and cones. This is why tapered roller bearings are designed into almost every industry, particularly large diameter tapered roller bearings.

Product number

Part No.	BOUNDARY DIMENSIONS (in m.m.)					LOAD RATING		LIMITING SPEED (R.P.M.)		MASS
Part No.	d	D	B	C	T	STATIC (Co) KN	DYNAMIC (C) KN	Grease	Oil	(~ Kg.)
72212 / 72487	53.975	123.825	32.791	25.4	36.512	165	145	2850	4000	2.03
JW 5549/JW5510	55	115	31	23.5	34	161.9	126	3000	4000	1.558
387 / 382	57.15	98.425	21.945	17.825	21	102	80.9	3800	5000	0.63
482 / 472	69.85	120	29.007	24.237	29.795	188.6	131.2	3000	4000	1.33
47487 / 47420 X	69.85	120	32.545	26.195	32.545	26.195	32.545	3000	4000	1.5
566 / 563	69.85	127	36.17	28.575	36.512	254.7	176.6	2800	3800	1.945
JW 7049 / JW 7010	70	140	35.5	27	39	244	180.3	2400	3200	2.65
47490/47420	71.438	120	32.545	26.195	32.545	218.1	149.1	3000	4000	1.42
HM 215249/HM 215210	75.987	131.975	39	32	39	280.8	196.9	2600	3500	2.11
34300 / 34478	76.2	121.442	23.012	17.463	24.608	127.6	90.8	2900	3800	0.954
6461/6420	149.225	54.229	44.45	53.975	410.6	287.9	2400	2400	3200	4.185

Taper Roller Bearings Applications

➀ Given description is only for information purpose and we accept no responsibility for any mistakes, erros and others

➁ Weight less than 0.001 kg/0.002 lb is indicated like 0.001 kg/0.002 lb Send request

➂ Drawing does not show all technical details of item button
